Features:
aluminum window and door sliding punching press machine
1. Steel welded body, tempering treatment, high rigidity, accuracy and stability;
2. Vertical located crankshaft, compact structure;aluminum window and door sliding punching press machine
3. Lengthened rectangular guideway with a surface of bronze plate;
4. Pneumatic dual balance cylinder, which balances the slide block and punch weight to reduce noise and impact;
5. PLC control and imported safety dual valve;aluminum window and door sliding punching press machine
6. Dry clutch and hydraulic overload protector.aluminum window and door sliding punching press machine
7. CE certificate.aluminum window and door sliding punching press machine
Standard Equipments:
1) Wet clutch
2) PLC
3) Hydraulic overload protecting pump
4) Touch screen
5) Cam controller
6) Die height adjusted motor (SYA-60 and upon models)
7) Auto lubrication system
8) Manual lubrication system
9) Double hand control panel
10) Electronic crankshaft angle indicator
11) Predetermined counter
12) Balance cylinders for slide and upper die
13) Work light
14) Joint for air
15) Joint for miss-feeding
16) Absorbing pads
Optional Equipments:
1) Dry clutch
2) Light curtain
3) Foot pedal
4) Die cushion
5) Inverter
6) Variable speed motor
7) Auto feed shaft
8) Die quick change device
Specification
| Specification | Unite | SYA-25 | SYA-35 | SYA-45 | SYA-60 |
| Model | | V | H | S | V | H | V | H | V | H |
| Capacity | Ton | 25 | 35 | 45 | 60 |
| Rated tonnage point | mm | 3.2 | 1.6 | 3.2 | 3.2 | 1.6 | 3.2 | 1.6 | 4 | 2 |
| Speed changing | S.p.m | 60-140 | 130-200 | 60-120 | 40-120 | 110-180 | 40-100 | 110-150 | 35-90 | 80-120 |
| Stable speed | S.p.m | | 110 | 110 | | 85 | 75 | 65 |
| Stroke | mm | 70 | 30 | 80 | 70 | 40 | 80 | 50 | 120 | 60 |
| Die height | mm | 195 | 215 | 190 | 220 | 235 | 250 | 265 | 10 | 340 |
| Slide adjustment | mm | 50 | 50 | 55 | 60 | 75 |
| Slide area | mm | 300×230×50 | 360×250×50 | 400×300×60 | 500×360×70 |
| Bolster area | mm | 680×300×70 | 800×400×70 | 850×440×80 | 900×500×80 |
| Shank hole | mm | Ø38.1 | Ø38.1 | Ø38.1 | Ø50 |
| Main motor | Kw.p | 3.7×4 | 3.7×4 | 5.5×4 | 5.5×4 |
| Slide adjust device | HP | manual operation |
| Air pressure | Kg/cm² | 6 | 6 | 6 | 6 |
| Presses precision | | GB/JIS 1class |
| Presses dimension | mm | 1280×850×2200 | 1380×900×2400 | 1600×950×2500 | 1600×1000×2800 |
| Presses weight | Ton | 2.1 | 3 | 3.8 | 5.6 |
| Die cushion capacity | Ton | - | 2.3 | 2.3 | 3.6 |
| Stroke | mm | - | 50 | 50 | 70 |
| Die cushion effective area | mm² | - | 300×230 | 300×230 | 350×300 |
